Description
Efficient Narrow Frame Aluminium Scaffolding Solutions for Limited Spaces
Orgean designs Narrow Frame Aluminium Scaffolding specifically for projects where space is limited and a single-width scaffold fits best. Featuring a lightweight aluminium frame and durable chrome-plated body, this scaffolding system guarantees safety and ease of use. Moreover, its compact design lets workers access tight areas that larger scaffolds simply cannot reach.
Key Features and Benefits
This scaffold’s narrow frame suits confined workspaces such as industrial maintenance zones, hospitals, or interior construction sites. Additionally, the frame includes a six-rung ladder that customers can customize to their needs. The system offers enhanced mobility and safety with caster wheels featuring a dual braking system. Furthermore, workers can operate safely at multiple levels thanks to the scaffold’s multi-level working capability. The system complies fully with UAE safety standards, supporting a maximum safe working height of 12 meters. For extra stability, workers should install stabilizers when working above five meters. Finally, the scaffold’s lightweight construction enables fast assembly and dismantling, which reduces downtime and labor costs.
Technical Specifications and Sizes
| Specification |
Details |
| Material |
Aluminium 6061 T6 |
| Frame Finish |
Chrome Plated |
| Base Width |
0.8 m |
| Base Length |
1.8 m |
| Platform Load Capacity |
225 kg |
| Total Tower Load |
700 kg |
| Maximum Platform Height |
11.0 m |
| Maximum Working Height |
13.0 m |
Tower Sizes & Working Heights for Narrow Aluminium Scaffolding
| Tower Code |
Tower Height (m) |
Platform Height (m) |
Working Height (m) |
| ANLS 2 |
2.0 |
1.0 |
3.0 |
| ANLS 3 |
3.0 |
2.0 |
4.0 |
| ANLS 4 |
4.0 |
3.0 |
5.0 |
| ANLS 5 |
5.0 |
4.0 |
6.0 |
| ANLS 6 |
6.0 |
5.0 |
7.0 |
| ANLS 7 |
7.0 |
6.0 |
8.0 |
| ANLS 8 |
8.0 |
7.0 |
9.0 |
| ANLS 9 |
9.0 |
8.0 |
10.0 |
| ANLS 10 |
10.0 |
9.0 |
11.0 |
| ANLS 11 |
11.0 |
10.0 |
12.0 |
| ANLS 12 |
12.0 |
11.0 |
13.0 |
Component Breakdown for Narrow Frame Aluminium Scaffold Kits
| Tower Code |
Frames 2m |
Guardrail 1m |
H-Braces 1.8m |
D-Braces 2m |
Stabilizer 3m |
Stabilizer 4.5m |
Stabilizer 6m |
6” Castors |
8” Castors |
Trapdoor Platform |
| ANLS 2 |
2 |
0 |
4 |
2 |
0 |
0 |
0 |
4 |
0 |
1 |
| ANLS 3 |
2 |
2 |
6 |
2 |
0 |
0 |
0 |
4 |
0 |
1 |
| ANLS 4 |
4 |
0 |
6 |
4 |
0 |
0 |
0 |
4 |
0 |
1 |
| ANLS 5 |
4 |
2 |
6 |
6 |
4 |
0 |
0 |
4 |
1 |
1 |
| ANLS 6 |
6 |
0 |
8 |
8 |
4 |
0 |
0 |
4 |
1 |
1 |
| ANLS 7 |
6 |
2 |
8 |
10 |
4 |
0 |
0 |
4 |
1 |
1 |
| ANLS 8 |
8 |
0 |
8 |
12 |
0 |
4 |
0 |
4 |
1 |
1 |
| ANLS 9 |
8 |
2 |
10 |
14 |
0 |
4 |
6 |
4 |
1 |
1 |
| ANLS 10 |
10 |
0 |
10 |
16 |
0 |
4 |
0 |
4 |
1 |
1 |
| ANLS 11 |
10 |
2 |
10 |
18 |
0 |
4 |
0 |
4 |
1 |
1 |
| ANLS 12 |
12 |
0 |
12 |
20 |
0 |
0 |
4 |
4 |
1 |
1 |
Accessories to Enhance Safety and Performance
| Accessory Name |
Specification / Size |
Function |
Remarks |
| Trapdoor Platform |
Standard Narrow Frame Size |
Provides safe access and working platform |
Mandatory for working height |
| 6” Dual Brake Castor Wheels |
Heavy-Duty Swivel Castor |
Mobility with secure locking system |
Standard supply |
| 8” Castor Wheels |
Extra Heavy-Duty Castor |
Improved movement on uneven surfaces |
Optional |
| Guardrails |
1.0 m Aluminium Guardrail |
Fall protection at platform level |
Required above specified height |
| Toe Boards |
Standard Aluminium Toe Board |
Prevents tools and materials from falling |
Optional |
| Stabilizer Legs |
3 m / 4.5 m / 6 m |
Enhances tower stability |
Required from 5 m height and above |
What’s Included in the Scaffold Kit
- Trapdoor Platforms
- 6” Dual Brake Castor Wheels (Optional: 8”)
- H-Braces and D-Braces
- Guardrails
- Optional Toe Boards
- Ladder Frame (Chrome Plated)
- Stabilizer Legs (2.0m from 5m height and above)
Common Applications in Construction and Maintenance
Orgean’s narrow frame aluminium scaffolding suits MEP projects, HVAC installations, ceiling work, and more. It also works well in hospitals, schools, airports, residential, and commercial interiors. Event setup and AV installations benefit from its compact, mobile design. Overall, this scaffolding solution fits any construction zone with limited space.
